滅菌グレードフィルター
（低吸着）

Purcise SLT フィルター
滅菌グレードフィルター
（低吸着）

推奨の業界アプリケーション：

お見積りのお問い合わせ

概要製品性能ご注文情報

概要

特徴

低細胞毒性
低吸着

アプリケーション

培養液調製

Quality Control

出荷前完全性試験を100％実施
フルトレーサビリティ
ISO 9001承認工場での製造

产品性能

構成材料

Membrane	Hydrophilic polyethersulfone (PES)
Support	Polypropylene (PP)
Core/Cage/End Caps	Polypropylene (PP)
Cartridge End Cap Inserts	Polybutylene terephthalate (PBT) (Cartridge exclusive)
Cartrdige End Cap O-rings	Silicone / EPDM / Fluoroelastomer / PFA encapsulated O-rings
Capsule Housing	Polypropylene (PP)
Capsule Vent O-rings	Silicone

ろ過面積

Type	Effective Filtration Area
A-Standard Cartridge (10 inch)	0.55 m²

最大使用差圧

A-Standard Cartridge/ H-High Area Cartridge 1	Capsule
Forward： 0.69 MPa @ 25 °C 0.40 MPa @ 60 °C 0.24 MPa @ 80 °C Reverse： 0.30 MPa @ 25 °C 0.10 MPa @ 80 °C	Forward： 0.55 MPa @ 25 °C 0.10 MPa @ 80 °C Reverse： 0.21 MPa @ 25 °C

Sterlilization

Type	Sterilization
A - Standard Cartridge	Can be steam sterilized for 30 minutes at 135 °C with 50 cycles (< 30 kPa) Can be autoclaved 50 cycles for 30 minutes at 130°C
Capsule	Autoclavable capsules only: Can be autoclaved 25 cycles for 30 minutes at 130°C, (Can not be steam sterilized in-line)
	Gamma compatible capsules: Can be sterilized by gamma irradiation at 25-45 kGy or can be autoclaved 5 cycles for 60 minutes at 126 °C. (Can not be steamed in-line)
	Sterile capsule: Can be sterilized by gamma irradiation at 25-45 kGy
	Cleansteam bag sterile package: Pre-sterilized with autoclave for 30 minutes at 121°C

* Notes: Gamma sterilized products cannot be re-sterilized with gamma irradiation or steam sterilization

規制対応＊

USP<788> Particulate matter in large volume injectionに適合
21 CFR 210.3(b)(6) Non-fiber-releasing filterに適合
ASTM F838 10⁷ cfu/cm² Brevundimonas diminuta (ATCC 19146)に適合
USP <85> Limulus Amebocyte Lysate (LAL)の0.25EU/ml未満に適合
USP <87> In Vitro Biological Reactivity Testに適合
USP <88> Biological Reactivity Test for Class V-121 °C plasticsに適合
FDA 21 CFR177-18 indirect food additive requirementsに適合
動物由来成分不使用

ご注文情報

Filter Cartridge

Cartridge Format	Membrane Type	Length	End Cap	O-ring Material	Industry
A Standard Cartridge	SLTS 0.45+0.2 μm	02 2.5 inch	0 DOE	S Silicone	P
H High Area Cartridge 1 (0.69-0.8m²)	SLTH 0.65+0.2 μm	05 5 inch	2 226 / Flat	E EPDM
L High Area Cartridge 2 (1.0-1.2m²)	SLTL 0.8+0.2 μm	10 10 inch	7 226 / Fin	V Fluoroelastomer
		20 20 inch	3 222 / Flat	P FEP/PFA encapsulated O-rings
		30 30 inch	8 222 / Fin
		40 40 inch	6 222/3-Flange bayonet/Fin

Bricap C Series Capsule Filter

Capsule Format	Inlet/Outlet	Membrane Type	Sterilization	Package	Industry
C01	T 19 mm(3/4'') Sanitary Flange	SLTS 0.45+0.2μm	A Autoclavable	1 1/pk	P
C02	K 14 mm (9/16") Sanitary Flange	SLTH 0.65+0.2μm	G Gamma Compatible
C03	F 31 mm (1 1/4") Sanitary Flange	SLTL 0.8+0.2μm	S Sterile
	V 14 mm (9/16") Hose Barb		C Cleansteam Bag Sterile Package
	H 13 mm (1/2") Hose Barb
	Y 9.6 mm (3/8") Hose Barb
	L 3.2 mm (1/8") Hose Barb
	B 6-13 mm (1/4"-1/2") Stepped Hose Barb (No Filling Bell)
	A 6-13 mm (1/4"-1/2") Stepped Hose Barb with Filling Bell (Outlet Only)

Bricap D Series Capsule Filter

Capsule Format	Inlet/Outlet	Membrane Type	Sterilization	Package	Industry
D01	B 6-13 mm (1/4"-1/2") Stepped Hose Barb (No Filling Bell)	SLTS 0.45+0.2μm	A Autoclavable	1 1/pk	P
	A 6-13 mm (1/4"-1/2") Stepped Hose Barb with Filling Bell (Outlet Only)	SLTH 0.65+0.2μm	G Gamma Compatible
		SLTL 0.8+0.2μm	S Sterile
			C Cleansteam Bag Sterile Package

Bricap L Series Capsule Filter

Capsule Format	Inlet/Out	Membrane Type	Sterilization	Package	Industry
L02	S 38 mm (1 1/2") Sanitary Flange	SLTS 0.45+0.2μm	A Autoclavable	1 1/pk	P
L03	T 19 mm (3/4") Sanitary Flange	SLTH 0.65+0.2μm	G Gamma Compatible
L05	K 14 mm (9/16") Sanitary Flange	SLTL 0.8+0.2μm	S Sterile
L10	D 25 mm (1") Hose Barb		C Cleansteam Bag Sterile Package
L20	M 19 mm (3/4") Hose Barb
L30	X 16 mm (5/8") Hose Barb
	V 14 mm (9/16") Hose Barb
	H 13 mm (1/2") Hose Barb
	Y 9.6 mm (3/8") Hose Barb

Bricap T Series Capsule Filter

Capsule Format	Inlet/Outlet	Gauge Port Type	Membrane Type	Sterilization	Package	Industry
T10	SS 38 mm (1 1/2") Sanitary Flange Inlet & Outlet	S 38 mm (1 1/2") Sanitary Flange	SLTS 0.45+0.2μm	A Autoclavable	1 1/pk	P
T20	SM 38 mm (1 1/2") Sanitary Flange Inlet & 19 mm (3/4") Hose Barb Outlet	T 19mm (3/4") Sanitary Flange	SLTH 0.65+0.2μm	G Gamma Compatible
T30		N Without Gauge Port	SLTL 0.8+0.2μm	S Sterile
				C Cleansteam Bag Sterile Package

Brisip SP3 Series Capsule Filter

Capsule Format	Inlet/Outlet	Membrane Type	Vent and Drain Valves	Package	Industry
SP3	S 38 mm (1 1/2") Sanitary Flange	SLTS 0.45+0.2μm	P Both using 6 mm hose barb	1 1/pk	P
		SLTH 0.65+0.2μm	X Vent valve using quick coupling (compatible with Stäubli connector), and drain valve using 6 mm hose barb
		SLTL 0.8+0.2μm	T Both using quick coupling (compatible with Stäubli connector)
			V Both using 13 mm (1/2") sanitary flange

BriScale A50 Liquid Disc Filter

Filter Format	Inlet/Outlet	Membrane Type	Sterilization	Package	Industry
A50	BB 6-13 mm (1/4"-1/2") Stepped Hose Barb Inlet & Outlet (No Filling Bell)	SLTS 0.45+0.2μm	A Autoclavable	1 1/pk	P
	BA 6-13 mm (1/4"-1/2") Stepped Hose Barb Inlet & Outlet (Outlet with Filling Bell)	SLTH 0.65+0.2μm	G Gamma Compatible
		SLTL 0.8+0.2μm	S Sterile

Bricap SFU Series Syringe Filter (No Vent）

Filter Format	Inlet/Outlet	Membrane Type	Sterilization	Package	Industry
U13	CP Female Luer Lock Inlet and Male Luer Lock Outlet	SLTS 0.45+0.2μm	A Autoclavable	1 1/pk	P
U25		SLTH 0.65+0.2μm	G Gamma Compatible
U33		SLTL 0.8+0.2μm	S Sterile

Bricap SFV Series Syringe Filter（With Luer Vent）

Filter Format	Inlet/Outlet	Membrane Type	Sterilization	Package	Industry
V25	CP Female Luer Lock Inlet and Male Luer Lock Outlet	SLTS 0.45+0.2μm	A Autoclavable	1 1/pk	P
		SLTH 0.65+0.2μm	G Gamma Compatible
		SLTL 0.8+0.2μm	S Sterile

*Example：ASLTS020SP (Standard Cartridge，Purcise SLT 0.45+0.2µm，2.5 inch，DOE，Silicone，Pharmaceutical Grade)
